Vanguard 12,000 BTU mini split | 24 SEER2 | Wi-Fi | Up to 750 sq. ft.
Vanguard 12,000 BTU mini split | 24 SEER2 | Wi-Fi | Up to 750 sq. ft.
Regular price
$1,189.00 USD
Regular price
Sale price
$1,189.00 USD
Year-round heating and cooling for living rooms, master bedrooms, and open-plan spaces. Whisper-quiet, energy-smart, and built to perform even when outdoor temperatures drop to -13°F.
Heats down to -13°F — where most mini splits give up
24 SEER2 — among the highest efficiency ratings in this class
30 dB(A) quiet — quieter than a library whisper
SKU:
View all specs
Model : SAC12SNV23-1
View full details
Built for better living, every season
Every feature in the Vanguard is designed to make your home more comfortable, more efficient, and healthier — without adding complexity to your life.
Reliable heat when it matters most
While most mini splits struggle in deep winter, the Vanguard keeps delivering — 8,900 BTU at 5°F, 7,800 BTU at 17°F. Heating mode operates down to -13°F, so your living space stays warm through the coldest nights.
Lower energy bills, every single month
At 24 SEER2 — among the highest efficiency ratings in this category — the Vanguard draws measurably less power than competing 12,000 BTU units rated at 19–21.5 SEER2. Energy Star and AHRI certified, so the savings are real, not estimated.
A home that stays peaceful
30 dB(A) indoor operation — quieter than most room AC units. Whether you're entertaining, working, or winding down, you'll notice the comfort before you notice the unit.
Control your climate from anywhere
Adjust temperature, set schedules, and switch modes from your smartphone. Works with Alexa and Google Assistant for hands-free voice control. A backlit remote with 24-hour timer means it works without Wi-Fi too.
Cleaner air, without the maintenance headaches
High-temp self-clean heats the coil to sterilizing temperature, eliminating mold and bacteria at the source — no service call required. Filter change alerts and built-in self-diagnosis keep everything running at its best.
Ready to install. Nothing left to source.
Ships complete with a 25 ft pre-charged line set, wall mounting bracket, outdoor pad, and washable dust filter. No refrigerant tank needed on site. Professional installation required.
Thoughtfully engineered, inside and out
Inverter compressor
Energy-saving, stable temperatures
24 SEER2
Among the highest efficiency ratings in its class
R32 refrigerant
Lower environmental impact than R410A
8 comfort modes
Auto, Cool, Heat, Dry, Fan, Turbo, Sleep, Eco
4-way auto swing
Even airflow in every direction
iFeel / Follow Me
Adjusts to where you are in the room
Wi-Fi + app control
Manage comfort from anywhere
Alexa & Google Assistant
Hands-free voice control
High-temp self-clean
Automatic coil sterilization
Refrigerant leak detector
Built-in safety protection
Chassis heater
Cold climate reliability
Modular PCB design
Easier servicing, longer life
Backlit remote
24-hour timer — no Wi-Fi needed
Top-access washable filter
Simple upkeep, no tools required
Auto restart
Resumes after power interruptions
5-year compressor warranty
Built to outlast the competition
Product technical specifications
Full performance, installation, and dimensional details for the Vanguard 12,000 BTU mini split | 24 SEER2 | Wi-Fi | Up to 750 sq. ft.
| Specification | Value |
|---|---|
| Cooling capacity | 12,000 BTU (range: 2,500–12,500 BTU) |
| Heating capacity | 12,400 BTU (range: 2,500–15,000 BTU) |
| Heating capacity @ 5°F | 8,900 BTU |
| Heating capacity @ 17°F | 7,800 BTU |
| Cold climate operation | Down to -13°F |
| SEER2 | 24 |
| EER2 @ 95°F | 13 |
| HSPF | 10 |
| Coverage area | Up to 750 sq ft |
| Inverter | Yes |
| Zone | Single zone |
| Moisture removal | 1.4 L/h |
| Specification | Value |
|---|---|
| Indoor noise level | 46 / 44 / 36 / 32 / 30 dB(A) |
| Outdoor noise level | 56 dB(A) |
| Airflow (Low / Med / High) | 323 / 411 / 470 CFM |
| Operating modes | Auto, Cool, Heat, Dry, Fan-Only, Turbo, Sleep, Eco |
| Auto swing | 4-way (up/down + left/right) |
| iFeel / Follow Me | Yes |
| Louver position memory | Yes |
| Frost protection | 46°F (8°C) |
| Set point temperature range | 60.8°F – 87.8°F |
| Specification | Value |
|---|---|
| Energy Star certified | Yes |
| AHRI certified | Yes |
| Refrigerant | R32 |
| Refrigerant charge | 27.2 oz |
| Additional charge rate | 0.56 oz/ft |
| Specification | Value |
|---|---|
| Voltage | 115V |
| Rated input power (cooling) | 920W |
| Rated input power (heating) | 920W |
| Rated current (cooling) | 8A |
| Rated current (heating) | 8A |
| Minimum circuit ampacity | 10A |
| Maximum overcurrent protection | 15A |
| Pre-charged line set | 25 ft |
| Maximum lineset length | 49 ft |
| Maximum elevation difference | 33 ft |
| Connecting pipe — gas line | 3/8" |
| Connecting pipe — liquid line | 1/4" |
| Connecting wiring | 4 × 16AWG |
| Estimated installation time | ~2 hours |
| Condensate drain method | Gravity |
| Specification | Outdoor Unit (ODU) | Indoor Unit (IDU) |
|---|---|---|
| Dimensions (W × D × H) | 31-1/2" × 12" × 21-3/4" | 36-1/4" × 7-5/8" × 12" |
| Net weight | 58.0 lbs | 22.0 lbs |
| Gross weight | 64.5 lbs | 28.6 lbs |
| Specification | Value |
|---|---|
| Wi-Fi app control | Yes |
| Local on-device scheduling | Yes |
| Alexa | Yes |
| Google Assistant | Yes |
| Apple HomeKit | No |
| Geofencing | No |
| Filter change alert | Yes |
| Self-diagnosis | Yes |
| Timer | Yes |
| Display on/off | Yes |
| °C / °F switch | Yes |
| Specification | Value |
|---|---|
| Self-clean | Yes |
| High-temp self-clean & sterilization | Yes |
| Deep-clean air channel | Yes |
| Filter type | Washable (top-access) |
| Specification | Value |
|---|---|
| Compressor warranty | 5 years |
| Parts warranty | 1 year |
| Registration required | No |
| Coil anti-corrosion coating | Yes |
| Refrigerant leak detector | Yes |
| Chassis heater (cold climate) | Yes |
| Fire-rated electrical box | Yes |
| Modular PCB design | Yes |
| Advanced defrost logic | Yes |
| Auto restart | Yes |
| Forced defrost | Yes |
| Specification | Value |
|---|---|
| Compressor brand | GMCC |
| Compressor type | Rotary |
| Compressor model | KSN98D31UEZA31 |
