Vanguard 9,000 BTU mini split | 23 SEER2 | Wi-Fi | Up to 450 sq. ft.
Vanguard 9,000 BTU mini split | 23 SEER2 | Wi-Fi | Up to 450 sq. ft.
Regular price
$1,079.00 USD
Regular price
Sale price
$1,079.00 USD
Year-round heating and cooling for bedrooms, home offices, and living spaces. Whisper-quiet, energy smart, and built to perform even when outdoor temperatures drop to -13°F.
Heats down to -13°F — where most mini splits give up
23 SEER2 — Energy Star & AHRI certified
30 dB(A) quiet — quieter than a library whisper
SKU:
View all specs
Model : SAC09SNV23-1
View full details
Built for better living, every season
Every feature in the Vanguard is designed to make your home more comfortable, more efficient, and healthier — without adding complexity to your life.
Reliable heat when it matters most vanguard 9k
While most mini splits struggle in deep winter, the Vanguard keeps delivering — 7,500 BTU at 5°F, 6,200 BTU at 17°F. Heating mode operates down to -13°F, so you stay warm through the coldest nights.
Lower energy bills, every single month
At 23 SEER2, the Vanguard runs measurably more efficiently than the 19–21.5 SEER2 average for this class. Energy Star and AHRI certified — so the savings are real, not estimated.
A home that stays peaceful
30 dB(A) indoor operation — quieter than most room AC units. Whether you're sleeping, working, or just unwinding, you'll notice the comfort before you notice the unit.
Cleaner air, automatically
High-temp self-clean heats the coil to sterilizing temperature and purges the indoor unit automatically — no service call, no mold buildup. Filter change alerts keep air quality consistently at its best.
Precision control, beautifully simple
A backlit remote with 24-hour timer gives you complete control over temperature, modes, and scheduling — from the moment you walk in the door.
Ready to install. Nothing left to source.
Ships complete with a 25 ft pre-charged line set, wall mounting bracket, outdoor pad, and washable dust filter. No refrigerant tank needed on site. Professional installation required.
Thoughtfully engineered, inside and out
Inverter compressor
Energy-saving, stable temperatures
23 SEER2
Among the most efficient in its class
R32 refrigerant
Lower environmental impact than R410A
4-way auto swing
Even airflow in every direction
High-temp self-clean
Automatic coil sterilization
Chassis heater
Cold climate reliability
Wi-Fi & app control
Manage comfort from anywhere
5-year compressor warranty
Built to outlast the competition
Backlit remote
24-hour timer — no Wi-Fi needed
Product technical specifications
Full performance, installation, and dimensional details for the Vanguard 9,000 BTU mini split | 23 SEER2 | Wi-Fi | Up to 450 sq. ft.
| Specification | Value |
|---|---|
| Cooling capacity | 9,000 BTU (range: 2,400–11,000 BTU) |
| Heating capacity | 10,000 BTU (range: 2,400–11,000 BTU) |
| Heating capacity @ 5°F | 7,500 BTU |
| Heating capacity @ 17°F | 6,200 BTU |
| Cold climate operation | Down to -13°F |
| SEER2 | 23 |
| EER2 @ 95°F | 13 |
| HSPF | 10 |
| Coverage area | Up to 450 sq ft |
| Inverter | Yes |
| Zone | Single zone |
| Moisture removal | 0.6 L/h |
| Specification | Value |
|---|---|
| Indoor noise level | 43 / 40 / 33 / 31 / 30 dB(A) |
| Outdoor noise level | 54 dB(A) |
| Airflow (Low / Med / High) | 188 / 235 / 282 CFM |
| Operating modes | Auto, Cool, Heat, Dry, Fan-Only, Turbo, Sleep, Eco |
| Auto swing | 4-way (up/down + left/right) |
| iFeel / Follow Me | Yes |
| Louver position memory | Yes |
| Frost protection | 46°F (8°C) |
| Set point temperature range | 60.8°F – 87.8°F |
| Specification | Value |
|---|---|
| Energy Star certified | Yes |
| AHRI certified | Yes |
| Refrigerant | R32 |
| Refrigerant charge | 19.4 oz |
| Additional charge rate | 0.56 oz/ft |
| Specification | Value |
|---|---|
| Voltage | 115V |
| Rated input power (cooling) | 653W |
| Rated input power (heating) | 634W |
| Rated current (cooling) | 5.8A |
| Rated current (heating) | 5.7A |
| Minimum circuit ampacity | 16A |
| Maximum overcurrent protection | 25A |
| Pre-charged line set | 25 ft |
| Maximum lineset length | 49 ft |
| Maximum elevation difference | 33 ft |
| Connecting pipe — gas line | 3/8" |
| Connecting pipe — liquid line | 1/4" |
| Connecting wiring | 4 × 16AWG |
| Estimated installation time | ~2 hours |
| Condensate drain method | Gravity |
| Specification | Outdoor Unit (ODU) | Indoor Unit (IDU) |
|---|---|---|
| Dimensions (W × D × H) | 38-1/2" × 16-5/8" × 31-5/8" | 43-1/4" × 8-3/4" × 13-1/8" |
| Net weight | 99.2 lbs | 30.9 lbs |
| Gross weight | 107.8 lbs | 37.4 lbs |
| Specification | Value |
|---|---|
| Wi-Fi app control | Yes |
| Local on-device scheduling | Yes |
| Alexa | Yes |
| Google Assistant | Yes |
| Apple HomeKit | No |
| Geofencing | No |
| Filter change alert | Yes |
| Self-diagnosis | Yes |
| Timer | Yes |
| Display on/off | Yes |
| °C / °F switch | Yes |
| Specification | Value |
|---|---|
| Self-clean | Yes |
| High-temp self-clean & sterilization | Yes |
| Deep-clean air channel | Yes |
| Filter type | Washable (top-access) |
| Specification | Value |
|---|---|
| Compressor warranty | 5 years |
| Parts warranty | 1 year |
| Registration required | No |
| Coil anti-corrosion coating | Yes |
| Refrigerant leak detector | Yes |
| Chassis heater (cold climate) | Yes |
| Fire-rated electrical box | Yes |
| Modular PCB design | Yes |
| Advanced defrost logic | Yes |
| Auto restart | Yes |
| Forced defrost | Yes |
| Specification | Value |
|---|
